3KW high voltage pure sine wave solar inverter with 80A MPPT charge controller high voltage
3KW high voltage pure sine wave solar inverter with 80A MPPT charge controller high voltage
- The solar inverter is the heart of small solar systems and is suitable for remote regions with and without power supply.
- It delivers continuous 230V AC power with 3000W pure sine wave, ideal for lighting throughout the home.
- The MPPT solar charge controller features maximum efficiency in solar energy production and conversion.
- With WiFi functionality and a downloadable app, you can easily view energy consumption and other data on your smartphone.
- The integrated MPPT 80A charge controller enables optimal energy management for your solar system.
| Rated power | 3000W | ||
| Battery Voltage | 24VDC | ||
| Product Size(L*W*Hmm) | 350x259x90 | ||
| NW(Kg) | 5 | ||
| Solar | MPPT tracking voltage range | 90V-430V | |
| Max PV input voltage | 450V | ||
| PV array maximum power | 3000W | ||
| AC input | AC input voltage range | 170VAC~280VAC(UPS mode) | |
| AC input frequency range | 50Hz/60Hz | ||
| output | Output efficiency(Battery/PV Mode) | 94%(Peak value) | |
| Output Voltage(Battery/PV Mode) | 220VAC±2%/230VAC±2%/240VAC±2% | ||
| Output Frequency(Battery/PVMode) | 50Hz or 60Hz | ||
| Output Wave(Battery/PV Mode) | Pure Sine Wave | ||
| Efficiency(AC Mode) | >99% | ||
| Battery |
Battery Type |
VRLA Battery | Charge Voltage :13.8V; Float Voltage:13.7V(Single battery voltage) |
| Customize battery |
Charging and discharging parameters of different types batteries can be customized according to user requirements |
||
| Max AC charging current | 60A | ||
| Max PV Charging Current | 80A | ||
| Working fashion | Mains priority/Solar priority/Battery priority(Can be set) | ||
| Transfer time | ≤4ms | ||
| display | LCD+LED | ||
| Communication(Optional) | RS485/APP(WIFI monitoring or GPRS monitoring) | ||
| Environmen | Operating temperature | 0℃~55℃ | |
| Storage temperature | -15℃~60℃ | ||
| Noise | ≤55dB | ||
| elevation | 2000m(More than derating) | ||
| Humidity | 0%~95%(No condensation) | ||
A single unit measures 350 * 259 * 90 mm and weighs 5 kg.
Dieses multifunktionale Wechselrichter-/Ladegerät kombiniert die Funktionen eines Wechselrichters, eines Solarladegeräts und eines Batterieladegeräts, um eine unterbrechungsfreie Stromversorgung in tragbarer Größe zu gewährleisten. Sein umfassendes LCD-Display bietet benutzerkonfigurierbare und leicht zugängliche Drucktastenfunktionen wie Batterieladestrom, Priorität des AC-/Solar-Ladegeräts und zulässige Eingangsspannungen für verschiedene Anwendungen.
