Hybrid inverter 8.2 KW DC48V AC230V 160A MPPT

Hybrid inverter 8.2 KW DC48V AC230V 160A MPPT

Regular price €559.00
Sale price €559.00 Regular price €699.00
Unit price
Description
Reviews
Shipping & Returns
【Pure sine Wave Inverter】 8200W Pure sine Wave Inverter is a new all-in-one hybrid solar inverter charger, Support dual PV input, dual MPPT voltage tracking.RGB lingthing for different working mode(Purple-PV Mode;Red-Battery Mode ;Blue utility mode)
【TECHNICAL SPECIFICATIONS】 8.2KW Hybrid Solar Inverter Max.PV Input Power: 8200W, Voltage range: 90-450Vdc, Max.PV Input VOC: 500V DC, Starting voltage >150V; The best working voltage is 300-360V;Recommended PV cable size: 10AWG, Max. charge current: 160A. Nominal Input Frequency: 50/60Hz; Output Power: 8200W, surge Capacity: 16400W.fit for 48V Lead-Acid (Seal, AGM,Gel, Flooded) and Lithium battery
【MULTIPLE CHARGING MODES】 Off Grid Solar Inverter have 4 charging modes are optional, ie Only Solar, Mains Frist , Solar Frist and Mains & Solar hybrid charging; and 3 output modes are available, ie Solar Frist, Mains Frist and SBU Priority, uninterrupted power supply to meet different application requirements. And compatible to mains voltage or generator power, Auto restart while AC is recovering.
【New features】 Built-in BMS function. Lithium Battery Activation, has a reactivation feature to awaken a sleeping lithium battery. The small charge current to activate the protection circuit and if a correct cell voltage can be reached, it starts a normal charge.Dual AC output, one for the main load (UPS function), one for the conventional load.

【WIDE RANGE OF USES】 MPPT Inverter Charger Pure sine Wave 8200W for RV Camping Boat Home Emergency ect.. Can be accessed to a variety of household and office loads, including Oven, rice cooker, lamps, televisions, fans and other AC loads. (Be careful not to install it near the bedroom, the fan will make a sound when the inverter is running. Avoid affecting your rest

【SongSolar can offer you a battery pack.】

The battery capacity of the correct matching system is determined according to the specific usage requirements of the load and application scenarios, otherwise it is easy to cause insufficient battery capacity or excessive waste of power generation. For details, please refer to the manual recommendation or contact online customer service.

Introduction:

This is a multi-function inverter/charger that combines the functions of inverter, solar charger and battery charger to
uninterruptible power supply with portable size.
Its comprehensive LCD display offers user-configurable and easily accessible button functions such as battery charging current,
AC/Solar charger priority and the allowable input voltage for different applications.


Features of 48VDC solar power inverter:

1. pure sine wave solar inverter
2) Output power factor 1.0
3.wifi&GPRS available for IOS and Android
4.dual MPPT input, dual AC output
5.built-in 160A MPPT solar charge controller
6. High PV input voltage range (120~500VDC)
7.built anti-twilight kit for harsh environment
8.smart battery charger design for optimized battery life
9.RGB switches automatically with the working mode of the machine
10. On/off-grid, touch screen display
11.the inverter runs without a battery

Basic system architecture:

The following figure shows the basic application for this inverter/charger. It also includes the following devices to run a complete system:
1.Generator or power supplier.
2.PV modules Ask your system integrator about other possible system architectures depending on your requirements. This inverter can power all kinds of devices at home or office, including motor-driven devices such as tube lights, fans, refrigerators and air conditioners.

Four modes can be selected when charging the battery:

First the power grid: First the battery is charged by the power grid, then by solar energy.
Solar Power First: Solar power charges the battery as the first priority source, then the grid power supply.
Solar and grid power (standard): Solar power and grid power charge the battery at the same time.

Solar only: Solar energy is the only source to charge the battery.
